MENRED Q6 Energy Recovery Dehumidifier | Fresh Air & Humidity Control Solution

MENRED Q6 Energy Recovery Dehumidifier | Fresh Air & Humidity Control Solution

Brand Name	MENRED
Model Number	Q6
Type	Energy Recovery Fresh Air Dehumidifier
Power Supply	220-240V~ 50/60Hz
Rated Airflow	500m³/h
Dehumidification Capacity	80L/day
Product Dimensions	1300 × 750 × 350mm

Features

ERV Dehumidification up to 80L/Day
Provides 80L/D ERV dehumidification capacity under 30°C / 80%RH conditions for integrated fresh-air humidity control.

Integrated Fresh Air & Dehumidification
Combines energy recovery ventilation and dehumidification in one centralized unit, reducing the need for separate ventilation and moisture-control equipment.

300m³/h Rated Airflow
Provides 300m³/h rated airflow with a maximum airflow of up to 500m³/h.

Heat Recovery Function
Provides 65% heating efficiency and 57% cooling efficiency to recover energy during fresh air ventilation.

98% Fresh Air Ratio
Delivers a fresh air ratio of up to 98% for effective outdoor air replacement.

G4 + HEPA Filtration
Multi-stage filtration helps reduce airborne particles from incoming outdoor air.

97% PM2.5 Filtration
Provides up to 97% PM2.5 filtration efficiency for cleaner supplied fresh air.

Low-Noise DC Fan
Equipped with a DC fan and operates at approximately 34dB(A).

Ceiling-Mounted Design
Concealed ceiling installation integrates with centralized ductwork while saving usable indoor floor space.

Benefits

Fresh Air & Humidity Control in One Unit
Q6 combines ventilation, heat recovery, filtration and dehumidification, simplifying whole-home indoor air treatment.

Helps Maintain Comfortable Humidity
High-capacity dehumidification helps reduce excess indoor moisture and improve comfort in humid environments.

Reduced HVAC Energy Loss
Heat recovery helps retain part of the heating or cooling energy that would otherwise be lost during ventilation.

Cleaner Indoor Air
G4 + HEPA filtration and 97% PM2.5 filtration help reduce particulate pollutants entering with outdoor air.

Suitable for Whole-Home Applications
A 300m³/h rated airflow and applicable area of up to 200m² support centralized residential ventilation and humidity control.

Quiet Daily Operation
Approximately 34dB(A) operating noise supports comfortable residential use.

Space-Saving Centralized Solution
Ceiling-mounted installation keeps the unit concealed while ductwork distributes treated fresh air throughout the home.

Specification

Specification	Details
Product Dimension:	1420 × 800 × 270mm
Brand Name:	MENRED
Model Number:	Q6
Power Supply:	220–240V~ 50/60Hz
Rated Airflow:	300m³/h
Max Airflow:	500m³/h
Rated Power:	660W
Dehumidification:	42L/D (30°C / 80%RH)
ERV Dehumidification:	80L/D (30°C / 80%RH)
ERV Dehumidification Power:	620W
Cooling Efficiency:	57%
Heating Efficiency:	65%
Fresh Air Ratio:	98%
PM2.5 Filtration:	97%
Motor/Fan:	DC Fan
Filter:	G4 + HEPA
Noise:	34dB(A)
Weight:	83kg
Applicable Area:	Up to 200m²
Outdoor Temperature:	-10°C to 50°C
Installation:	Ceiling-Mounted
Type:	ERV Dehumidifier

Documenls

Access documentation, including installation guides, owner manuals, specification sheets, and more, to help you get the most out of your product.

Access Product Documentation

Service

menred q6 energy recovery dehumidifier fresh air humidity control solution-3

BIM Design

menred q6 energy recovery dehumidifier fresh air humidity control solution-4

OEM/ODM

menred q6 energy recovery dehumidifier fresh air humidity control solution-5

Transport

menred q6 energy recovery dehumidifier fresh air humidity control solution-6

Quality guarantee

MENRED Q6 Energy Recovery Dehumidifier

Smart Fresh Air & Humidity Control Solution

The MENRED Q6 is a smart fresh air dehumidification system designed for residential applications. Equipped with energy recovery technology, efficient DC fan, and intelligent humidity control, the Q6 delivers fresh air while reducing energy loss and maintaining comfortable indoor humidity. With quiet operation, powerful dehumidification capacity, and flexible ceiling installation, it is an ideal solution for villas, apartments, and residential projects.
