MENRED G7 Wall-mounted ERV Fresh Air System 350m³/h ebmpapst DC Fan G4+HEPA Heat Recovery Ventilator with Built-in Air Quality Sensor

· Different Names of Product: Wall-mounted ERV, Wall-hung Heat Recovery Ventilator, Vertical Wall HRV Fresh Air System, No-ceiling Energy Recovery Ventilation Unit, Whole House Wall Air Exchanger

· Main Application: Indoor air renewal for villas, large finished apartments, homestays and offices; no ceiling breaking required, exhaust indoor stale air and deliver purified fresh outdoor air, recycle heat energy to cut air conditioning power consumption, filter PM2.5, formaldehyde and excess CO₂ to improve indoor air quality for fully decorated houses.

· Core Specification: Model G7, Rated airflow 350m³/h, Max airflow 450m³/h, applicable area up to 200㎡, 220V~50Hz power supply, Germany ebmpapst DC fan, built-in multi-function air quality sensors, Japan Toray G4+HEPA dual filtration with 98% PM2.5 filtering efficiency, heating recovery efficiency73% / cooling recovery efficiency65.5%, fresh air ratio98.2%, running noise39dB(A), net weight57Kgs, dimension940×630×405mm, optional touch screen controller and matched full ductwork, support Tuya APP WIFI remote control.

MENRED G7 wall-mounted vertical ERV fresh air system is a space-saving wall-hung energy recovery ventilation unit customized for fully decorated villas and large apartments that cannot implement ceiling concealed pipeline construction. It adopts vertical wall-mounted installation design without any ceiling disassembly or pre-buried construction, perfectly solving the fresh air renovation pain point of finished houses and old buildings, and matching various indoor decoration styles.

Equipped with original Germany ebmpapst DC fan as core air supply component, the unit runs stably with ultra-low rated power of only 130W, controlling operating noise at 39dB(A) to avoid sound interference to daily rest and office work. Its supply fan static pressure reaches 80Pa and exhaust fan static pressure is 50Pa, which supports long-distance multi-room duct layout to send uniform fresh air to every separated room. Built-in integrated high-precision air quality sensors can real-time detect indoor PM2.5, CO₂, temperature and humidity data, automatically adjust fan speed according to air pollution concentration to realize unattended intelligent on-demand ventilation.

This wall-mounted ventilator is fitted with imported Japan Toray filter material to build G4 primary filter + HEPA high-efficiency composite purification structure, achieving 98% PM2.5 interception efficiency to block outdoor haze, pollen, fine dust and floating allergens, while efficiently adsorb formaldehyde, benzene and other volatile harmful substances left after interior decoration. The built-in high-efficiency total heat exchanger fully recycles temperature and humidity energy contained in exhausted indoor waste air, reaching 73% heating heat recovery efficiency and 65.5% cooling recovery efficiency, which effectively reduces extra energy loss of air conditioning and heating equipment caused by fresh air temperature difference, significantly cutting household long-term electricity expenditure.

Powered by standard 220V~50Hz power supply, G7 owns rated airflow of 350m³/h and maximum airflow up to 450m³/h, matching applicable indoor area up to 200 square meters, widely suitable for large duplex apartments, villas, boutique homestays and independent office ventilation renovation projects. Its fresh air ratio hits 98.2%, continuously input high-proportion pure fresh outdoor oxygen into closed indoor space, thoroughly solving indoor hypoxia, stuffiness, peculiar smell and excessive carbon dioxide concentration caused by long-time window closing.

The vertical wall-hung body dimension is 940×630×405mm with net weight of 57Kgs, lightweight structure simplifies wall fixing installation and shortens on-site construction period greatly. Customers can optionally configure intelligent touch screen controller and complete matched ductwork system, supporting Tuya APP WIFI remote monitoring, parameter setting and timing operation for remote intelligent control. All MENRED G7 series pass strict multi-process factory aging inspection and international CE, UKCA safety certifications. Stable monthly production capacity supports OEM customized logo and packaging service for global fresh air distributors, interior decoration companies and homestay engineering contractors.

· Finished High-end Residence: Decorated villas, large finished apartments and renovated old houses, no ceiling breaking required, realize whole-house fresh air purification without damaging original decoration layout.

· Light Hospitality Spaces: Boutique homestays, vacation suites and small inns, vertical wall-mounted design fits various interior decoration styles, keep guest rooms dry, oxygen-rich and fresh.

· Independent Office & Study: Private offices, large study rooms and personal studios, relieve indoor stuffiness and high CO₂ concentration from long-time closed windows to improve work efficiency and comfort.

· Renovation Light Engineering Projects: Special wall-hung fresh air equipment for interior decoration companies, the optimal ventilation upgrade solution for fully decorated houses unable to do ceiling concealed pipeline construction.

· Vertical Wall-mounted No-ceiling Design: No ceiling disassembly and pre-buried pipeline construction needed, ideal for finished house fresh air renovation, easy and fast installation.

· Germany ebmpapst Original DC Fan: Ultra-low rated power 130W, stable quiet operation at 39dB(A), long service life and low later maintenance failure rate.

· Built-in Integrated Air Quality Sensors: Real-time full-index indoor air monitoring, automatic fan speed adjustment for energy-saving intelligent ventilation operation.

· Japan Toray Dual-stage High-efficiency Filtration: G4 pre-filter + HEPA composite filter with 98% PM2.5 interception efficiency, thoroughly purify incoming fresh air and block outdoor haze, pollen and dust pollutants.

· Energy-saving High-efficiency Heat Recovery Core: 73% heating & 65.5% cooling recovery efficiency, recycle exhaust air temperature and humidity energy to cut annual air conditioning electricity cost obviously.

· 98.2% Ultra-high Fresh Air Ratio: Sufficient pure outdoor fresh oxygen input, effectively relieve indoor hypoxia, stuffiness and excessive CO₂ caused by long-time window closing.

· Moderate Static Pressure Multi-room Duct Support: Supply static pressure up to 80Pa, support full duct layout to deliver fresh air evenly to all separated rooms of the house.

· Tuya WIFI Intelligent Remote Control: Optional touch screen controller and mobile APP remote operation, realize unattended automatic ventilation and timing management.

· Wide Working Temperature Adaptability: Stable operation under -15℃~50℃, adapt to cold northern winter and hot southern summer climate conditions.

· Complete International Certifications & Customization Support: CE/UKCA certified, stable monthly supply capacity accepts OEM logo and packaging customization for global bulk purchasers.
